| Models | TTS-32 | TTS-38 | TTS-45 | TTS-50 |
| Screw Diameter | 32 mm | 38 mm | 45 mm | 50 mm |
| L/D Ratio | 28:1 | 28:1 | 28:1 | 28:1 |
| Tube Size Range | 1 to 20 mm | 1 to 32 mm | 3 to 30 mm | 3 to 38 mm |
| Extruder Motor | 3.70 KW | 5.00 KW | 5.00 KW | 7.50 KW |
| Tube Puller Motor | 0.37 KW | 0.75 KW | 0.75 KW | 0.75 KW |
| *Output Kg./Hour | 12-14 | 19-22 | 26-28 | 28-32 |
| Total Connected Load | 7.4 KW | 9.7 KW | 11.5 KW | 13.5 KW |
Online cutters for cutting long and small pieces of tubes are different and customized according to customer requirements. Online cutters are equipped with servo motor, controller & encoder or magnetic clutch brake & encoder for precise and accurate cutting length. A winder with a traverse assembly is provided for flexible tubes, if required. Die and calibrating systems will be different for different items/tubes/profiles.
Jockey Extruder will be required to be connected with the Plant for making lining on outer surface of tube/ straw or pen barrel.
