For making medical use tubes for I V set, scalp vein tubes, Rail tubes, Blood & urine tubes. SPVC Blown film/ sheet Plants for making PVC Blood & urine pouches also available.
| Models | TTX-45 | TTX-50 |
| Screw Diameter | 45 mm | 50 mm |
| L/D Ratio | 26:1 | 26:1 |
| Tube Size Range | 1 to 30 mm | 1 to 38 mm |
| Extruder Motor | 5.0 KW | 7.5 KW |
| Tube Puller Motor | 0.75 KW | 0.75 KW |
| *Output Kg./Hour | 20-24 | 28-32 |
| Total Connected Load | 12.5 KW | 14 KW |
Jockey Extruder will be required to be connected with the Non Toxic medical tube Plant for making RAIL TUBES.
